Streamfeeder ST-1450

The Streamfeeder ST-1450 has been designed for high-performance feeding and dispensing. Its intelligent system controller provides easy feature configuration. Compact footprint is ideal for in-line conveyor mounting. Use it in stand-alone applications as well as integrating into other systems. The Streamfeeder ST-1450 is capable of handling a wide variety of products, from single sheets to thick magazines.
applicationS:
(click to view video)

Streamfeeder Software Packaging

















technical data
Maximum Product Size:
(w/optional deck extension)
14.5 W x 9 L in (368 x 228 mm)
14.5 W x 14 L in (368 x 355 mm)
Minimum Product Size:
(optional):
3.75 W x 2.5 L in (95 x 63 mm)
2 W x 2.5 L in (51 x 63 mm)
Min/Max Product Thickness: .003-1.0 in (.076-25.4 mm)
Belt Speed :

5500 in/min (140,000 mm/min)

Electrical Requirements: 115/230vac, 50/60Hz, 3A
Weight: 84 lbs. (40.367 kg)
