Streamfeeder V-500

The Streamfeeder V-500 is designed to increase your 6x9 inserting, addressing base, and tabber base productivity. Adding a Streamfeeder V-500 to each station dramatically boosts inserter productivity. The Streamfeeder V-500 precisely separates, singulates, and presents many types and sizes of materials such as Z-fold sheets, slick stock, payment booklets, and other materials that are typically difficult to feed.

applicationS:
(click to view video)
Streamfeeder Gripper arm inserters
Streamfeeder Tabber bases















  features
  • Large capacity hopper - easy two knob adjustment
  • Tool-free adjustments for quick setup and changeover
  • Compact width for side-by-side mounting
  • Variable speed control for synchronous operation
  • Durable lightweight construction
  • Easy to learn and operate
technical data
Maximum Product Size: 9.25 W x 11 L in (235 x 279 mm)
Minimum Product Size: 2.125 W x 2.5 L in (54 x 63.5 mm)
Min/Max Product Thickness: .003-.625 in (.076-15.88 mm)
Belt Speed: 3400 in/min (86,360 mm/min)
Electrical Requirements: 115vac, 60Hz, 3A
Weight: 32 lbs. (14.5 kg)
