Streamfeeder V-710IJ

The Streamfeeder V-710IJ is for production mailing operations that demand maximum throughput from their ink jet printing, labeling, and tabbing bases. The lightweight Streamfeeder V-710IJ provides superior feeding to precisely separate and singulate many types and sizes of product. Job setups and changeovers are easily and quickly accomplished. The variable speed, clutch-free motor provides dependable feeding performance.

applicationS:
(click to view video)
Streamfeeder Tabber bases















  features
  • Durable steel construction/powder coat paint
  • Quality precision parts
  • Quick access split shell design
  • Variable speed DC motor
  • Adjustable feed belts for added feeding performance
  • Feeds tall stack heights of 8.5" x 11" and A4 sheets with ease
  • Advancing gate enables maintenance without stopping a job
  • Optional external run input for integrated start/stop control
technical data
Maximum Product Size: 12 W x 12 L in (305 x 305 mm)
Minimum Product Size:
(optional):
3.75 W x 3.75 L in (93 x 95 mm)
2.5 W x 2.5 L in (63 x 63 mm)
Min/Max Product Thickness: .003-.750 in (.076-19.1 mm)
Belt Speed: 5700 in/min (144,780 mm/min)
Electrical Requirements: 115/230vac, 50/60Hz, 3A
Weight: 41 lbs. (18.6 kg)
